Description:
V series features a 5MP digital camera and 3.5′ touch display screen to improve the working efficiency and imaging quality. Build-in laser ranging function meets the need of measuring targets in a safety distance. In functions, video & voice recording and Wi-Fi live streaming are added to make the device more playable. It is a reliable measurement tools widely used in industrial field.
It can be equipped with macro lens UT-Z003 (Optional), the recommended distance is 4 cm.
Features:
- 3.5″ IPS touch display screen (640×480 Pixels)
- IR resolution: 320×240
- Temperature measurement range: -40℃ to 400℃ / -40℉ to 752 ℉
- Auto alarm for HI/LO temperature
- Auto tracking for HI/LO spot
- On screen analyzer : 5 Points/1 Line/3 Rectangles/3 Circles
- Isotherm
- With 5MP digital camera
- 2x, 4x magnification
- 4 image modes (Thermal, Visual image, Fusion (T-Mix), PIP)
- QR Code – photo management
- Video & voice recording
- Laser pointer & laser ranging
- LED flashlight
- Wi-Fi connection through Mobile App – Wi-Fi live streaming is supported
- PC software: analysis and real-time image projection
- 5200mAh detachable battery pack (UT-M17)
- IP54
- 2m drop proof
Specifications:
Technical Data Display 3.5″ IPS Touch (640×480) IR resolution(Pixels) 320×240 Spectral range 8~14µm Pixel size 12µm Frame rate ≤9Hz Thermal sensitivity(NETD) ≤65mK Focus Focus Free Field of view(FOV) 56°(H) × 42°(V) Temperature measurement range -40℃~400℃ Accuracy ±2℃ or ±2% whichever is greater Functions Color palettes White Hot, Black Hot, Red Hot, Ironbow, Rainbow HC, Rainbow, Lava Image modes Thermal, Visual image, Fusion (T-Mix), PIP On screen analyzer 5 Points/1 Line/3 Rectangles/3 Circles Isotherm Auto/Manual Hi/Lo temperature alarm LCD animation, LED flashlight, Buzzer Hi/Lo temperature tracking √ Digital camera resolution 5MP Digital zoom 2x, 4x Video recording √ Voice recording √ Wi-Fi √ Wi-Fi live streaming √ LED lighting √ Laser pointer √ Laser distance measurement √ Analysis software PC+APP General Characteristics Battery 5200mAh detachable Li-ion battery pack (UT-M17) Operating time ≥4 hours (with Wi-Fi off) USB Type-C Storage 32GB Micro SD card Image storage format JPG Video storage format AVI Protection IP54 & 2m drop proof Certificates CE, UKCA, FCC, RoHS Languages EN, FR, DE, IT, ES, SV, PL, CZ Weight 654g Dimension 260mm×97mm×99mm Packing Details Standard accessories Type-C USB cable, Micro SD card, Li-ion battery pack×2, Quick Start Guide, Documents Download Operation Guide Standard individual packing Toolbox & Gift box Standard Qty per carton 1pcs Standard carton size 400mm×185mm×345mm Standard carton G.W. 4kg
