Features of UT60S Digital Multimeter
Certificates: CE, UKCA, cETLus
● 9999 counts
● True RMS
● Bluetooth
● Duty cycle
● Diode/Continuity test
● Temperature
● Non-contact voltage
● Analog bar/Data hold
● Backlight/Relative mode
● Auto/Manual range
● Low battery indication
● Three-color LED light indicator
Specifications of UT60S Digital Multimeter
| Function | Range | UT60S Accuracy |
|---|---|---|
| DC Voltage | 9.999mV / 99.99mV / 999.9mV / 9.999V / 99.99V / 999.9V | ±(0.5% + 3) |
| AC Voltage | 9.999mV / 99.99mV / 999.9mV / 9.999V / 99.99V / 999.9V | ±(0.8% + 3) |
| DC Current | 999.9μA / 999.9mA / 9.999A / 10A | ±(0.8% + 3) |
| AC Current | 999.9μA / 999.9mA / 9.999A / 10A | ±(1.0% + 3) |
| Resistance (Ω) | 999.9Ω / 9.999kΩ / 99.99kΩ / 999.9kΩ / 9.999MΩ / 99.99MΩ | ±(0.8% + 2) |
| Capacitance (F) | 9.999nF ~ 99.9mF | ±(4.0% + 5) |
| Frequency (Hz) | 99.99Hz ～ 9.999MHz | ±(0.1% + 5) |
| Duty Cycle | 0.1% ～ 99.9% | ±(3% + 5) |
| Temperature | –40℃ ～ 1000℃ / –40°F ～ 1832°F | ±4℃ / ±5℉ |
Features – UT60S
-
Display Count: 9999
-
Auto Range: ✔
-
REL Mode: ✔
-
NCV (Non-Contact Voltage): ✔
-
Diode Test: ✔
-
Continuity Test: ✔
-
Acousto-optic Indication: ✔ (NCV / continuity / battery power)
-
Low Battery Indication (≤3.6V): ✔
-
Data Hold Function: ✔
-
Auto Power Off (after 15 mins): ✔
-
Operating Temperature: 0℃ ～ 40℃
-
Safety Rating: CAT II 1000V / CAT III 600V
General Characteristics – UT60S
-
Battery: 3 × 1.5V AAA
-
Color: Red and Gray
-
Net Weight: 290g
-
Product Size: 169mm × 81mm × 46mm
-
Standard Accessories: Gift box, manual, thermocouple
-
Carton Packing:
-
Quantity: 20 pcs
-
Size: 420mm × 320mm × 300mm
Applications:
-
UT60S Temperature Measurement UT60S voltage measurement
