Description
Manufacturer’s designation: STM32F429 How can I program a popular microcontroller of the STM32F4 series? You can learn it with the help of the STM32F429-Discovery and realize own applications. An introduction in the ARM technology with modern touch display make it possible for newcomers and professionals. The STM32F429-Discovery use the ARM Cortex M4 controller STM32F429ZIT6 and has included ST-Link/V2 to programm and debug. It has also a touch grafic LCD, a 3 axes acceleration sensor and gyroscope, an additional SDRAM 64 Mbits for high-definition grafic and a free programable USB conect.
Properties
- microcontroller STM32F429ZIT6 (144 pins) with
- 32 Bit ARM Cortex-M4 MCU
- 180 MHz
- 2 MByte flash
- 256 KByte RAM
- 2.4″ color touch grafic LCD
- 2.4 inches
- 240 x 320 pixel, QVGA
- illumination
- 64 MBit SDRAM
- for graficdata with high color depth
- 3 axes acceleration sensor
- = digital gyroscope
- 6 LEDs
- 1 for USB communication
- 1 Power-LED for 3.3 V
- 2 for own use
- on-the-go 2 LEDs for USB
- 2 buton
- 1 for reset
- 1 for own use
- programmer onboard
|
 |
Functions
- ST-Link/V2 for programming and debugging onboard
With the help of a jumper the board also can be used as ST-Link/V2 for programming and debugging external microcontrollers (over SWD-connection)
- power supply of the board over USB or external over 3V e.g. 5V
- 3V and 5V are available for external peripheral equipment
- Connection external peripheral equipments over USB with micro USB-cable
- the pins of the microcontroller are outward over multi-pin connectors
|
example of use / tutorials
You can find helps for the programming of the display in our download-area and in the follow tutorials.
Please note: The tutorials are only in german.
|
|
Recommendation of software
Please Attention that SiSy Microcontroller++ is only in German.
The substantial range of function of this board is optimally supported by SiSy Microcontroller++ for the development of own program. SiSy Microcontroller++ is a software package for designing, writing, dating, burning and checking the self developed program. There are features of an easy development for programming available and its possible to work with UML. The own work will be optimized with a sample program and integrated facilities.
Here you can find continuing information about SiSy Microcontroller++. |
|
system requirements for Discovery-board
- PC with Windows XP / 7 / 8
- Mini USB-cable
|
system requirements for SiSy
-
- PC with Windows 2000 / XP / 2003 / Vista / 7 / 8 / 10
-
- (32-bit and 64-bit are supported)
|
|
Package Include:
1 x STM32F429 / 439 Arm Cortex M4
STM32F429 / 439 Arm Cortex M42 Bit ARM Cortex-M4 MCU180 MHz2 MByte flas256 KByte RAM ″ color touch grafic LCD240 x 320 pixel, QVGillumination MBit SDRAM
for graficdata with high color dept3 axes acceleration sensor1 for USB communication1 Power-LED for 3.3 Vb for own us
