Description:
The INSULATION TESTER ZC25H 1000V is a hand-cranked analog megohmmeter used to measure the insulation resistance of electrical equipment. The ZC25 series is a Chinese-made tester, and the “H” designation indicates a durable alloy housing.
Technical specifications:
- Test voltage: 1000V DC.
- Measuring range: 0 to 1000 MΩ.
- Accuracy: Grade 10, with a tolerance of ±10%.
- Rated cranking speed: 120 rotations per minute (r/min).
-
Operating conditions: Use the tester in temperatures from -25°C to 40°C with relative humidity below 80%.
Housing: The alloy shell (indicated by “H” in the model name) combines aluminum and plastic to provide durability.Other casing options in the ZC25 series include plastic, plastic spray-painted, and all-aluminum.
- Portability: Features a portable, lightweight design with a handle for easy carrying.
Applications:
The ZC25H is used for testing the insulation resistance of a variety of electrical equipment, including:
- Motors
- Cables
- Transformers
- Telecommunication components
- Household appliances
