Ygd75n65u1 IGBT Power Semiconductor

Then, enjoy strong and steady performance thanks to its durable TO-247 package. After that, use it confidently in inverters, motor drivers, UPS systems, and induction heating projects. Finally, trust its excellent thermal design for long-lasting and reliable use.

Key Features

• First, rely on the 650V voltage rating for strong high-voltage performance.
• Next, use the 75A current rating to handle heavy loads with ease.
• Then, enjoy simple mounting with the TO-247 package that ensures reliable heat management.
• After that, benefit from low switching loss and high input impedance for better efficiency.
• Also, use it confidently in high-frequency switching setups for smoother operations.
• Finally, count on it for powerful results in inverters, UPS systems, welding machines, and motor control projects.

Technical Specifications

• Collector-Emitter Voltage (V_CE): 650V
• Collector Current (I_C): 75A continuous
• Power Dissipation: High efficiency at full load
• Switching Speed: Fast
• Gate-Emitter Voltage: ±20V
• Package: TO-247 Fully Isolated

Related Product

• 9N90 MOSFET High Voltage N-Channel Power Transistor
• Irf740 n Channel Power Mosfet
• 52n15 MOSFET – High-Performance N-Channel Power MOSFET

Learn More

• Insulated-gate transistor
• Insulated Gate Transistor or IGBT
• A Complete Guide to IGBTs

Frequently Asked Questions (FAQs)

Q1: What are the voltage and current ratings of the YGD75N65U1?

A: It supports up to 650V and 75A continuous collector current.

Q2: Is it suitable for inverter circuits?

A: Yes, it is widely used in inverter circuits due to its fast switching and high efficiency.

Q3: What kind of package does it come in?

A: It comes in a durable TO-247 isolated case for better heat dissipation.

Q4: Can this IGBT be used for welding machines?

A: Absolutely. Its high power capability makes it perfect for industrial welding and UPS systems.

Package Includes

• 1 × YGD75N65U1 IGBT Power Transistor (TO-247 Package)
