Description

VICTOR VC-6017 Mini Clamp multimeter, clamp meter, digital ammeter

Item specifics

  • Brand Name:RUNDS
  • Measuring Inductance Range:NO
  • Display Type:Digital Only
  • Dimensions:138*62*26mm
  • Measuring Current Range:ACA 2000mA//20A/200A/500A
  • Operating Temperature:0-40
  • Measuring Voltage Range:ACV600V ;DCV600V
  • DIY Supplies:Electrical
  • Model Number:VC-6017
  • Measuring Resistance Range:R2000
  • Measuring Capacitance Range:NO
  • Weight:140g

FEATURES:

VC-6017 Mini Clamp multimeter, clamp meter, digital ammeter, ACA:. 0.01A-500A cost-effective, measurable voltage / current / resistance / buzzer …..function, ultra-high-precision ..

1, jaw opening 32mm;

2, portable design, one-hand operation, easy to use;

3, the first clamp with a double insulation protection, enhanced anti-jamming;

4, structural design stringent and reasonable.

Mini Clamp multimeterVC-6017  clamp meter digital ammeterVICTOR VC-6017VICTOR VC-6017 Mini Clamp multimeter, clamp meter, digital ammeter



SPECIFICATIONS of VICTOR VC-6017 Mini Clamp:

DC voltage: 600V ± (1.0% + 6)

AC voltage: 600V ± (1% + 10.)

AC current: 2000mA / 20A / 200A / 500A ± (2.5% + 8)

Resistance: 2000Ω ± (1.0% + 5)

Diode test

Off alarm

Low voltage display

Automatic negative polarity indication

Data Hold

Function protection

Input impedance: 10MΩ

Sampling frequency: 3 times / s

AC Frequency: (40-200) Hz

Manual range

Maximum display: 1999

Jaw opening: 32mm

Power: 1.5V AAA battery * 2

Color: dark gray + yellow clamp

Weight: about 140g

Size:138*62*26mm

Package : Gift Box

Packaging Details
  • Unit Type: piece
  • Package Weight: 0.35kg (0.77lb.)
