UT15B MAX series True RMS multi-meters have a compact and portable design, fast response, strong anti-interference to EMC interference, and come with standard gold-plated test leads and gold-plated fine-tipped test leads.They also feature full-range 1000V input protection, making them the ideal tool for electronic and electrical engineers.
Features of UT15B Max True RMS Digital Multimeter
Certificates: CE, UKCA, cETLus, REACH, RoHS
● True RMS measurement
● Compact design
● V.F.D function
● Fast measurement of Continuity
● Fast measurement of Capacitance
● Two test probes (standard & fine-tipped)
● Strong EMC anti-interference
● Full-range input protection
| Parameter | UT15B MAX |
|---|
| Certificates | CE, UKCA, cETLus, REACH, RoHS |
| Voltage (DC) | 600.0mV / 6.000V / 60.00V / 600.0V / 1000V ±(0.4%+3) |
| Voltage (AC) | 600.0mV / 6.000V / 60.00V / 600.0V / 1000V ±(0.5%+5) |
| VFD (Voltage) | 600.0V ±(8%) |
| Current (AC) | 600.0µA / 6000µA / 60.00mA / 600.0mA / 6.000A / 10.00A ±(1.2%+3) |
| Current (DC) | 600.0µA / 6000µA / 60.00mA / 600.0mA / 6.000A / 10.00A ±(1.2%+3) |
| Resistance | 600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ / 6.000MΩ / 60.00MΩ ±(0.5%+2) |
| Capacitance | 6.000nF / 60.00nF ~ 600.0µF / 6000µF ±(2.0%+5) |
| Frequency (Hz) | 10Hz ~ 10MHz ±(0.1%+3) |
| Duty Cycle | 1% ~ 99.9% ±(1.0%+4) |
| Temperature (℃/℉) | -55℃ ~ 500℃ / –67°F ~ 932°F |
Applications:
Voltage measurement (AC) VFD function (Frequency)
LED test (UT15B MAX only) Temperature measurement (UT17B/18B MAX)
