UT219DS Professional Clamp Meter is 600A true RMS professional clamp meter with CAT IV 600V rating. It is industrially designed with IP54 rating and able to withstand 2 meters drop test for measurement in harsh environments. This series is suitable for professional electricians, HVAC/R and motor service technicians.
Features of UT219DS:
1. LoZ input for ghost voltage measurement
2. Flashlight and auto backlight
3. 3-phase motor sequence test
4. Temperature and μA measurements (flame sensor)
5. Inrush current
6. AC+DC voltage
7. V+A dual display
Specifications
|
Range
|
UT219DS
|
| AC current (A) |
600A |
±(1.8%+6) |
| DC current (A) |
600A |
±(1.8%+6) |
| AC voltage (V) |
600V |
±(1%+6) |
| DC voltage (V) |
600V |
±(0.6%+3) |
| LoZ ACV |
600V |
±(2.5%+6) |
| Resistance (Ω) |
60MΩ |
±(1%+3) |
| Capacitance (F) |
60mF |
±(4%+7) |
| Frequency (Hz) |
600Hz~40MHz |
±(0.1%+6) |
| Duty cycle |
0.1%~99.9% |
±(2.6%+7) |
| Temperature |
-40~1000℃ |
±(2%+5℃) |
| -40~1832℉ |
±(2%+9℉) |
Secondary Features
|
| Display count |
|
6000 |
| Auto/Manual range |
|
√ |
| Jaw opening |
|
33mm |
| True RMS |
|
√ |
| AC current frequency response |
|
40Hz~400Hz |
| AC voltage frequency response |
|
40Hz~1kHz |
| 3-phase motor sequence test |
600V |
√ |
| Low pass filter |
1kHz, 3db attenuation |
√ |
| V+A displays voltage and current at the same time |
|
√ |
| Diode test |
|
3V |
| Measurement sampling rate |
|
5 times/s |
| Analog bar sampling rate |
|
20 times/s |
| Analog bar |
|
31 segment |
| Display interface (LCD) |
|
Dual |
| Auto power off/MAX/MIN |
|
√ |
| Low battery indication |
|
√ |
| Data hold (H)/Relative mode (REL) |
|
√ |
| ZERO mode |
|
√ |
| Function selection (SELECT) |
|
√ |
| Auto backlight/2m drop test |
|
√ |
| IP rating |
|
IP54 |
| Input impedance |
≥10MΩ |
√ |
General Characteristics
|
| Power |
1.5V battery (R03) x 3 |
| Display |
35mm x 31mm |
| Product color |
Red and grey |
| Product net weight |
310g |
| Product size |
234.6mm x 82mm x 47mm |
| Standard accessories |
Test leads, batteries, carrying bag, PC software CD, point contact temperature probe |
| Standard individual packing |
Gift box, blister, English manual (German, French, Spanish optional) |
| Standard quantity per carton |
10pcs |
| Standard carton measurement |
490mm x 295mm x 330mm |
| Standard carton gross weight |
8.2kg |
Package Includes:
- 1 x UT219DS Professional Clamp Meter
