Ntst20100ctg 20100ctg 20100 Trench-based Dual Schottky Rectifier, Very Low Forward Voltage, 20a, 100v

The NTST20100CTG is a 20A, 100V trench-based dual Schottky rectifier that delivers very low forward voltage drop. Unlike planar Schottky rectifiers, it reduces forward voltage without sacrificing reverse leakage, making it highly efficient. Moreover, the advanced trench technology ensures stable switching characteristics across a wide temperature range. Therefore, it serves as an ideal output rectifier for switching power supplies, including notebook and netbook adapters, ATX systems, and flat panel displays.

Key features:

• Dual configuration: Contains two separate diodes with their cathodes tied together at the center pin, which is useful for applications such as full-wave rectifiers with a center-tapped transformer.
• Trench-based technology: This manufacturing process allows for a very low forward voltage drop and low leakage current. This technology results in less power loss, higher efficiency, and lower operating temperature compared to planar Schottky rectifiers.
• High efficiency: With a very low forward voltage, the rectifier minimizes power loss and helps achieve regulatory compliance for energy efficiency.
• Fast switching: The device offers fast switching with exceptional temperature stability, which is essential for high-speed applications.
• High surge capability: The rectifier can withstand high surge currents.

Common applications:

• Output rectification for switching power supplies
• Notebook and Netbook adapters
• ATX power supplies
• Flat-panel displays

Package Includes:

1 x  NTST20100CTG
