G75H120DF1 IGBT – 75A 1200V High-Efficiency Power Transisto

Key Features

• Voltage rating: 1200V
• Current rating: 75A continuous
• Low saturation voltage (Vce(sat)) for improved efficiency
• Optimized for high-speed switching applications
• Robust TO-247 package for better thermal performance
• High durability for industrial and power electronics applications

Applications

• Motor drive systems
• Power inverters
• Uninterruptible Power Supplies (UPS)
• Renewable energy systems
• Industrial automation
• High-frequency power conversion circuits

Related Products

• Used 600V 100A G60N100
• 1200V 40A IGBT 40N120 High-Performance IGBT
• K75T60 IGBT IKW75N60T 600V 75A IGBT

Frequently Asked Questions

What is the voltage and current rating of the G75H120DF1 IGBT?

The G75H120DF1 is rated for 75A continuous current and 1200V maximum voltage.

Is this IGBT suitable for motor drives?

Yes, it is designed for industrial motor drives, power inverters, and high-efficiency energy conversion systems.

What is the package type of this IGBT?

The G75H120DF1 comes in a TO-247 package, which provides excellent thermal performance and easy integration into power circuits.

Package Includes

• 1x G75H120DF1 IGBT 75A 1200V
